Frame
Manufactured from lightweight, high tensile 1.5mm thick ‘Rustec’ steel.
Adjust 2-Fit side expander systmen that offers up to 24mm expansion to the structural opening.
Strongdor self adhesive neoprene teardrop asstandard.
Single rebate 104mm wide frame.

Leaf
44mm door leaf thickness, fitted with an integrated astragal for added security. Comprising of 2 x 1.5mm ‘Rustec’ steel sheets, the leaf skins are mechanically interlocked and internally bonded, providing greater stability and protection against de-lamination.

Certification
Certified by the Loss Prevention Certification Board to LPS 1175 B3 Issue 8 Cert/LPCB and LPS 1175 A5 Issue 8 Cert/LPCB.

Threshold
Industrial door threshold - 96mm
Standard aluminium theshold is Part M compliant and is fitted with a seal for outward opening door-sets.

Hardware
Available with Mico Modular and MSR Tindall hardware.

Finish
Supplied inclusive of a powder coated finish in a standard colour. Full range of RAL and BS colours available.

Suitable Substrate
Structural timber or steelwork, or brickwork/concrete blockwork.
*Not all substrates suitable with fire-rated door-sets.
