MH-T4041A Low Power Consumption Infrared Gas Sensor

Zhengzhou Winsen Electronics Technology Stand: 4/C57

Application

  • HVAC Refrigeration and Indoor Air Quality monitoring
  • Industrial Process and safety protection monitoring
  • Agricultural and animal husbandry production process monitoring

Features

  • High sensitivity, high resolution, fast response time, ultra-low power consumption
  • Provides a variety of output modes, such as UART and analog voltage
  • Temperature compensation, excellent linear output, excellent stability, long service life
  • Anti-water vapor interference, no poisoning, can directly replace the catalytic combustion principle sensor

Specifications

Model No.MH-T4041A
Detection GasHydrocarbon flammable gases
Working voltage3.3V~5.5V DC(powered by the safety grid)
Average Current<0.8mA
Deteciton Range0~10% Vol optional(refer to sheet 2)
Interface level3V
  Output signalUART(3.0Vor 5.0V)
Preheat Time<10s
Reponse TimeT90<15s
Working Temperature-20℃  ~60 ℃
Working Humidity0~95%RH(non-condensing)
DimensionΦ20mm×21.7mm
Weight8g
Life time>5 years
Protection LevelIP54
Power end, communication end Intrinsicsafety parameterUi=7.5VDC,Ii=200mA, Pi=375mW,Ci=4.5μF,Li=0mH

Sheet 2
GasMolecular formulaRangeResolutionDecimal placeAccuracyNote
  Methane  CH40~5.00% Vol  0.01% Vol2 decimal    ±3%FS(10℃-40℃)   ±5%FS(-20℃-10℃, 40℃-60℃)
0~10.00% Vol2 decimal
PropaneC3H80~100% LEL1% LELNone
IsobutaneC4H100~100% LEL1% LELNone

* The description and specifications might be changed without notice. Please contact us for the latest information before placing orders.
