Frame
Manufactured from lightweight, high tensile 1.5 mm thick ‘Rustec’ steel.
Adjust 2-Fit side expander system that offers up to 12mm expansion to the structural opening.

Leaf
44mm door leaf thickness incorporating an integrated astragal for added security. Comprising of 1.2mm ‘Rustec’ steel sheets, the leaf skins are mechanically interlocked and internally bonded, proving greater stability and protection against de-lamination.

Door ironmongery
Grade 13 stainless steel, twin bearing template drilled butt hinges with integral high security dog bolts are fitted as standard with CE marking. Other hardware available.

Finish
Supplied inclusive of a powder coated finish in a standard colour. Full range of RAL and BS colours available.

Options and Upgrades

• Vision panels in various panel formats and sizes, fire-rated for up to 120 minutes.
• Louvre panels designed to increase airflow in areas that need efficient ventilation, louvre panels offer a flexible solution without compromising security or structural integrity.
• Strongdor offers PAS 24 Fire rated louvres up to 508 X 1524mm.
• Variety of solid and glazed side and over panels.
• Available thermal upgrade up to 1.5Wm2K U-value.
